Tech Explainer: What is CXL — and how can it help you lower data-center latency?

High latency is a data-center manager’s worst nightmare. Help is here from an open-source solution known as CXL. It works by maintaining “memory coherence” between the CPU’s memory and memory on attached devices.

  • June 20, 2024 | Author: KJ Jacoby
Learn More about this topic

Article Key

Latency is a crucial measure for every data center. Because latency measures the time it takes for data to travel from one point in a system or network to another, lower is generally better. A network with high latency has slower response times—not good.

Fortunately, the industry has come up with an open-source solution that provides a low-latency link between processors, accelerators and memory devices such as RAM and SSD storage. It’s known as Compute Express Link, or CXL for short.

CXL is designed to solve a couple of common problems. Once a processor uses up the capacity of its direct-attached memory, it relies on an SSD. This introduces a three-order-of-magnitude latency gap that can hurt both performance and total cost of ownership (TCO).

Another problem is that multicore processors are starving for memory bandwidth. This has become an issue because processors have been scaling in terms of cores and frequencies faster than their main memory channels. The resulting deficit leads to suboptimal use of the additional processor cores, as the cores have to wait for data.

CXL overcomes these issues by introducing a low-latency, memory cache coherent interconnect. CXL works for processors, memory expansion and AI accelerators such as the AMD Instinct MI300 series. The interconnect provides more bandwidth and capacity to processors, which increases efficiency and enables data-center operators to get more value from their existing infrastructure.

Cache-coherence refers to IT architecture in which multiple processor cores share the same memory hierarchy, yet retain individual L1 caches. The CXL interconnect reduces latency and increases performance throughout the data center.

The latest iteration of CXL, version 3.1, adds features to help data centers keep up with high-performance computational workloads. Notable upgrades include new peer-to-peer direct memory access, enhancements to memory pooling, and CXL Fabric improvements.

3 Ways to CXL

Today, there are three main types of CXL devices:

  • Type 1: Any device without integrated local memory. CXL protocols enable these devices to communicate and transfer memory capacity from the host processor.
  • Type 2: These devices include integrated memory, but also share CPU memory. They leverage CXL to enable coherent memory-sharing between the CPU and the CXL device.
  • Type 3: A class of devices designed to augment existing CPU memory. CXL enables the CPU to access external sources for increased bandwidth and reduced latency.

Hardware Support

As data-center architectures evolve, more hardware manufacturers are supporting CXL devices. One such example is Supermicro’s All-Flash EDSFF and NVM3 servers.

Supermicro’s cutting-edge appliances are optimized for resource-intensive workloads, including data-center infrastructure, data warehousing, hyperscale/hyperconverged and software-defined storage. To facilitate these workloads, Supermicro has included support for up to eight CXL 2.0 devices for advanced memory-pool sharing.

Of course, CXL can be utilized only on server platforms designed to support communication between the CPU, memory and CXL devices. That’s why CXL is built into the 4th gen AMD EPYC server processors.

These AMD EPYC processors include up to 96 ‘Zen 4’ 5nm cores. Each core includes 32MB per CCD of L3 cache, as well as up to 12 DDR5 channels supporting as much as 12TB of memory.

CXL memory expansion is built into the AMD EPYC platform. That makes these CPUs ideally suited for advanced AI and GenAI workloads.

Crucially, AMD also includes 256-bit AES-XTS and secure multikey encryption. This enables hypervisors to encrypt address space ranges on CXL-attached memory.

The Near Future of CXL

Like many add-on devices, CXL devices are often connected via the PCI Express (PCIe) bus. However, implementing CXL over PCIe 5.0 in large data centers has some drawbacks.

Chief among them is the way its memory pools remain isolated from each other. This adds latency and hampers significant resource-sharing.

The next generation of PCIe, version 6.0, is coming soon and will offer a solution. CXL for PCIe6.0 will offer twice as much throughput as PCIe 5.0.

The new PCIe standard will also add new memory-sharing functionality within the transaction layer. This will help reduce system latency and improve accelerator performance.

CXL is also leading to the start of disaggregated computing. There, resources that reside in different physical enclosures can be available to several applications.

Are your customers suffering from too much latency? The solution could be CXL.
